01
Clean Room Wheel
OHT Wheels
Compact polyurethane driven, traveling and side-guide wheels for overhead hoist transport systems in clean-room automation.
Application-Matched Alternatives
Targeted alternatives for clean-room wheel applications
SGT develops application-matched polyurethane wheel alternatives for clean-room material-handling equipment where buyers are evaluating Blickle, CCI, Uchiyama, JESS, Hamanaka Caster Wheel, Colson Hydrotech and Albion Caster products.
- Germany: Blickle
- Japan: CCI, Uchiyama, JESS and Hamanaka Caster Wheel
- United States: Colson Hydrotech and Albion Caster
Options can be developed for projects requiring low-outgassing and low-particle-generation performance in controlled clean-room environments, subject to specification and test-method confirmation.
Replacement selection is confirmed case by case using customer drawings, dimensions, polyurethane or ESD requirements, hub material, load and travel speed. Third-party trademarks belong to their respective owners and are used only to identify the products for which an alternative may be requested; SGT is not affiliated with or endorsed by those manufacturers.
Application Overview
OHT wheels are designed for overhead hoist transport systems running on elevated tracks. The range includes driven wheels, guide wheels, traveling wheels and wheel sets.
- Custom polyurethane tread and hub configurations
- Dimensional and load matching based on equipment requirements
- Drawing-based production and inspection support
02
Side Guide Wheel
- Material
- MY97A+ESD
- Size
- D70 × W15
- Hub
- Aluminum
- Load
- Not specified
- Speed
- 210 m/min
03
04
05
06
Side Guide Wheel
- Material
- MY97A+ESD
- Size
- D60 × W21.2
- Hub
- Aluminum
- Load
- Not specified
- Speed
- 210 m/min
07
Side Guide Wheel
- Material
- MY97A+ESD
- Size
- D60 × W23
- Hub
- Aluminum
- Load
- Not specified
- Speed
- 210 m/min
08
09
Side Guide Wheel
- Material
- MY9804
- Size
- D42 × W18
- Hub
- Aluminum
- Load
- Not specified
- Speed
- 210 m/min
10
11
12
13
14
15
16
Specification note: The source presentation does not provide a diameter and width for Driven Wheel Set No. 12; this entry is therefore identified as a custom specification rather than assigning an unverified size.
Custom Engineering
Need a wheel matched to your equipment?
Send us your drawing, target load, travel speed and clean-room requirements. Our team will review the specification and recommend a suitable construction.
