01
Side Guide Wheel
- Material
- MY97A+ESD
- Size
- D90 × W42
- Hub
- Aluminum
- Load
- Not specified
- Speed
- 210 m/min
Clean Room Wheel
Stacker Crane Wheels
Polyurethane traveling and side-guide wheels for clean-room stacker crane systems, with aluminum or steel hubs and multiple load and speed configurations.
Application-Matched Alternatives
Targeted alternatives for clean-room wheel applications
SGT develops application-matched polyurethane wheel alternatives for clean-room material-handling equipment where buyers are evaluating Blickle, CCI, Uchiyama, JESS, Hamanaka Caster Wheel, Colson Hydrotech and Albion Caster products.
- Germany: Blickle
- Japan: CCI, Uchiyama, JESS and Hamanaka Caster Wheel
- United States: Colson Hydrotech and Albion Caster
Options can be developed for projects requiring low-outgassing and low-particle-generation performance in controlled clean-room environments, subject to specification and test-method confirmation.
Replacement selection is confirmed case by case using customer drawings, dimensions, polyurethane or ESD requirements, hub material, load and travel speed. Third-party trademarks belong to their respective owners and are used only to identify the products for which an alternative may be requested; SGT is not affiliated with or endorsed by those manufacturers.
Application Overview
Designed for clean-room stacker crane travel and guidance positions. The listed range covers compact guide wheels through large traveling wheels for demanding automated material-handling systems.
- Custom polyurethane tread and hub configurations
- Dimensional and load matching based on equipment requirements
- Drawing-based production and inspection support
02
Side Guide Wheel
- Material
- MY9804
- Size
- D150 × W40
- Hub
- Aluminum
- Load
- Not specified
- Speed
- 180 m/min
03
04
05
06
07
08
09
10
11
Specification note: Two D500 × W200 entries are retained as separate supplied variants because the source presentation shows two distinct product constructions with the same listed performance data.
Custom Engineering
Need a wheel matched to your equipment?
Send us your drawing, target load, travel speed and clean-room requirements. Our team will review the specification and recommend a suitable construction.
